FOX 2.5 HTO Shocks – Jeep Gladiator JT 2020+

$3,000.00

Engineered for high-performance off-road use, FOX 2.5 HTO Shocks deliver consistent damping and extra rebound control with advanced Hydraulic Top-Out technology. Built with a 2.5″ aluminum body, IFP design, and race-inspired pistons, they provide superior stability and cooling for lifted or heavily modified Gladiators. Perfect for desert runs, overlanding, and aggressive off-road builds. Fully rebuildable and tuned specifically for the JT platform. Backed by FOX’s elite suspension engineering.
Contact Us Now

American Builds Rating System

Build Type       Big Lapper

Towing

40%

Looks

60%

Interior

60%

Driveline / Performance

60%

Off Road Capability

60%

Modification Ability

90%

Towing Class

NILLightHeavy

Build Type       Big Lapper

Towing

65%

Looks

80%

Interior

60%

Driveline / Performance

60%

Off Road Capability

85%

Modification Ability

50%

Towing Class

NILLightHeavy
Tax included. Shipping calculated at checkout.

FOX 2.5 Hydraulic Top-Out (HTO) Shocks – Jeep Gladiator JT

Fitment: Jeep Gladiator JT (2020+)
Application: Front & Rear – Multiple lift heights available
Series: FOX Performance Elite 2.5 with Hydraulic Top-Out (HTO) Technology

Product Overview:

The FOX 2.5 Performance Elite HTO shocks are engineered for high-performance off-road use, offering consistent damping and additional rebound control via an internal Hydraulic Top-Out system. Specifically tuned for the Jeep Gladiator JT, these shocks provide enhanced handling and stability on modified vehicles with added weight or increased lift.

Key Specifications:

Feature Specification
Body Diameter 2.5″ (63.5mm)
Body Material Smooth bore 6061-T6 aluminum
Finish Hard-anodized, black
Shock Type Monotube with Internal Floating Piston (IFP)
Valving Proprietary HTO-specific valving – non-adjustable
Top-Out Control Hydraulic top-out zone integrated internally
Mounting Direct bolt-on to factory locations
Piston High-flow race piston design
Seals Industrial-grade sealing system
Oil JM92 advanced suspension fluid
Shaft Size 7/8″ (22mm) hard chrome-plated steel
Gas Charge High-pressure nitrogen, IFP-separated
Serviceability Fully rebuildable and revalvable
Lift Range Available in configurations for 0–1.5″, 2–3.5″, and 4–6″ lifts

Included in Kit:

  • 2x Front and 2x Rear FOX 2.5 HTO Shocks

  • Pre-installed bushings and sleeves

  • Vehicle-specific mounting hardware

  • Installation guide & support

Recommended Use Cases:

  • Off-road trail use

  • Long-distance overlanding

  • High-speed desert and dune driving

  • Heavily modified vehicles (large tyres, bumpers, racks, engine conversions)

Notes:

  • Designed for use with aftermarket or extended travel suspension systems and larger tyres

  • Requires matched spring rates for optimal performance

  • Sold individually or as a full front/rear set

Engineered in the USA. Distributed by American Builds – Australia’s FOX Jeep Specialist.
